Preface

Constructing a data pipeline is fundamental for deep learning projects. Introductory books often read the entire dataset into memory at once. That works for small datasets like MNIST, but for millions of images it is impossible. In this article we demonstrate how to load data only when needed.

Prerequisites

Before building the pipeline we need some advanced Python knowledge. Lists are common objects in Python, but why can we access items with []? The secret is the __getitem__() method of a class. By implementing __getitem__, a class can return values for a given index.

Suppose we have a class Demo with three attributes a, b and c mapped to strings. We want to access them using indices 0-2. We can implement __getitem__() as follows:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16

class Demo:
    def __init__(self):
        self.a = 'string_a'
        self.b = 'string_b'
        self.c = 'string_c'

    def __getitem__(self, index):
        match index:
            case 1:
                return self.a
            case 2:
                return self.b
            case 3:
                return self.c
            case _:
                raise IndexError(f'Given index: {index} out of range.')

We can instantiate Demo and fetch values with []:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10

demo = Demo()

print(demo[0])
# 'string_a'

print(demo[1])
# 'string_b'

print(demo[4])
# IndexError: Given index: 4 out of range.

This allows us to record image paths and read files from disk only when a specific index is requested.

PyTorch data pipeline basics

As mentioned, building an object with __getitem__() is called a Map Style Dataset 1. For PyTorch such a dataset must:

1. Inherit from torch.utils.data.Dataset
2. Implement __getitem__()

The first requirement inherits useful properties and methods. The second enables index-based access. If custom sampling is required, implement __len__() so DataLoader and Sampler can know the dataset length. Implementing __getitems__() can further speed up batch reading.

Simple example – build an image loading pipeline

Assume images are stored in an images folder with jpg files and labels in a label folder with text files of the same name. We want to load and preprocess data only when needed. A Map Style Dataset can achieve this.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29

import torch
import glob
import cv2
import torch.nn.functional as F
from torch.utils.data import Dataset

class ImageDataset(Dataset):
    def __init__(self, img_path, label_path, n_class=100, transform_fn=None):
        self.img_path = img_path
        self.label_path = label_path
        self.n_class = n_class
        self.transform_fn = transform_fn

        self.n_files = glob(f"{self.img_path}/*.jpg")

    def __len__(self):
        return self.n_files

    def __getitem__(self, index):
        if self.transform_fn is not None:
            _img = cv2.imread(self.img_path[index])
            _img = self.transform_fn(_img)
        else:
            _img = cv2.imread(self.img_path[index])

        with open(self.label_path[index], 'r') as file:
            _label = torch.tensor(int(file.readlines()[0]))

        return _img, F.one_hot(_label, num_classes=self.n_class)

Instantiate ImageDataset and wrap it with torch.utils.data.DataLoader while specifying batch_size, num_workers, etc. to complete the pipeline:

1
2
3
4
5

train_dataset = torch.utils.data.DataLoader(
    ImageDataset(img_path, label_path, n_class=800, transform_fn=my_transform),
    batch_size=2,
    num_workers=10,
)

Summary

We introduced how to build a Map Style Dataset that loads data on demand. PyTorch also provides IterableDataset 2 for other scenarios, which we may cover in the future.
