Introduction

Airflow can be deployed in many ways. In this post we demonstrate how to deploy Airflow with Docker Compose.

Prerequisites

• Docker CE, Docker Desktop, or OrbStack installed
• Docker Compose version v2.14.0 or newer
• At least 4GB of RAM

Download configuration file

To deploy Airflow with Docker Compose we first need the docker-compose.yaml file. Download it from the Airflow website or run:

1

curl -LfO 'https://airflow.apache.org/docs/apache-airflow/2.10.0/docker-compose.yaml'

Components

The configuration file defines the components required by Airflow:

• airflow-scheduler – monitors DAGs and tasks, triggering task instances when dependencies are met
• airflow-webserver – Airflow web interface available at http://localhost:8080
• airflow-worker – executes tasks assigned by the scheduler
• airflow-triggerer – runs event loops for deferrable tasks
• airflow-init – initialization service
• postgres – database
• redis – broker that forwards messages from the scheduler to workers

Start Airflow services

By default the configuration starts Airflow with CeleryExecutor and binds several directories into the containers. The root directory can be configured through AIRFLOW_PROJ_DIR in the .env file. If not set, the directory where you run docker-compose is mounted and the following subdirectories are created:

• dags – place DAG files
• logs – contains task and scheduler logs
• config – add custom log formatters or airflow_local_settings.py
• plugins – place custom plugins

Before starting the services, add the following to .env:

1

echo -e "AIRFLOW_UID=$(id -u)" > .env

Then start the services:

1

docker-compose up -d

The Airflow web UI is available at http://localhost:8080.

Configuration guide

Set Airflow image version

The script pulls image v2.10.0 from Docker Hub by default. To change the version, set the following variable in .env:

1

AIRFLOW_IMAGE_NAME=apache/airflow:<your option>

Monitor Celery with Flower

Flower is disabled by default. Enable it with:

1

docker-compose up flower

or

1

docker-compose up -d --profile flower

The Flower UI is available at http://localhost:5555.

Use a custom image

• Build while starting

  Docker Compose allows building images when starting containers instead of building them beforehand. See the Docker Compose build documentation.

• Build ahead of time

  Build the image first and specify it with the AIRFLOW_IMAGE_NAME variable.

Clean up

To stop Airflow and clean up generated data and unused containers:

1

docker-compose down --volumes --remove-orphans

References

• Airflow documentation – Running Airflow in Docker
